Interference Analyzer (Option 25) 3-12 Zero Span IF BW Menu (Option 89)
Spectrum Analyzer MG PN: 10580-00349 Rev. H 3-37
3-12 Zero Span IF BW Menu (Option 89)
Zero Span IF bandwidth provides a nominal 140 MHz IF signal out of a BNC female
connector. The IF output signal is present only when the instrument span is set to zero by
pressing the Zero Span key in the Span menu. Press the Zero Span submenu key again to
access the Zero Span IF BW menu.
When Normal is selected, the IF bandwidth is influenced by the RBW setting. The selectable
bandwidth values may differ among instrument types.
Key Sequence: Freq > Span > Zero Span
Note
Option 89 is not available on all instrument models. Refer to your instrument
Technical Data Sheet.
Normal: Press this key to select a bandwidth based on the RBW setting.
The selectable fixed bandwidth values listed below may differ depending on
your instrument.
7MHzBW: Press this button to select a fixed IF bandwidth of 7 MHz.
10 MHz BW: Press this button to select a fixed IF bandwidth of 10 MHz.
16 MHz BW: Press this button to select a fixed IF bandwidth of 16 MHz.
32 MHz BW: Press this button to select a fixed IF bandwidth of 32 MHz.
Back: Returns to the Span menu.
Figure 3-30. Zero Span IF BW Menu
Zero Span IF BW
Back
7 MHz BW
10 MHz BW
16 MHz BW
32 MHz BW
Normal
