Coverage Mapping (Option 431) 6-4 Coverage Mapping
Spectrum Analyzer MG PN: 10580-00349 Rev. H 6-11
Opening the KML file automatically launches Google Earth if the application is not yet open.
Figure 6-5 illustrates a sample coverage mapping .kml file viewed in Google Earth. You can
also view the file with Google Maps, provided you have the appropriate plug-in for your
browser.
Save Tab Delimited Points
In the Coverage Mapping submenu, press Save/Recall Points/Map, then Save Tab Delimited
Points. In the Save dialog, change the file name as appropriate, then press Enter. A tab
delimited text file (.mtd) of the coverage mapping data currently displayed on the screen will
be saved to the default location.
Figure 6-5. Sample Coverage Mapping KML File in Google Earth
