7-6 RF Span Menu
Key Sequence: Freq > Span
Span: Press to set the RF Span. If you use the numeric keypad to enter a
value, then the submenu keys change to Units of GHz, MHz, kHz, or Hz.
Pressing the Enter key is the same as pressing the MHz submenu key. You
may also use the rotary knob or the arrow keys, then press the Enter key.
Span Up: Press to increase the Span. If starting at 10 kHz, the span
increases to 20 kHz, 50 kHz, 100 kHz, 200 kHz, 500 kHz, 1 MHz, 2 MHz,
5 MHz and 10 MHz. Each press of this submenu key increases the span to
one of these listed values.
Span Down: Press to decrease the Span. If starting at 5 MHz, then span
decreases to 2 MHz, 1 MHz, 500 kHz, 200 kHz, 100 kHz, 50 kHz, 20 kHz,
and 10 kHz. Each press of this submenu key decreases the span to one of
these listed values.
Max Span: Press to set the span to 10 MHz, the maximum value.
Min Span: Press to set the span to 10 kHz, the minimum value.
Last Span: Press to set the span to the previously set span value.
Back: Press to return to the RF Freq menu.
Figure 7-10. RF Span Menu
Back
Max Span
Min Span
Last Span
Span Up
1 – 2 – 5
Span
## MHz
Span Down
1 – 2 – 5
RF Span
