Anritsu Spectrum Master MS2720T - Amplitude Menu

AM/FM/PM Analyzer (Option 509) 7-8 Amplitude Menu
Spectrum Analyzer MG PN: 10580-00349 Rev. H 7-15
7-8 Amplitude Menu
Key Sequence: Amplitude
Scale: Press to set the scaling factor in dB per division. Use the rotary knob,
the arrow keys, or the numeric keypad, then press the Enter key.
Power Offset: Press to set the power offset in dB. Use the rotary knob, the
arrow keys, or the numeric keypad, then press the Enter key.
Adjust Range: Press to change the reference level if the signal strength is
too high (ADC error) or too low.
Figure 7-12. Amplitude Menu
Power Offset
## dB
Scale
## dB/div
Adjust
Range
RF Amplitude
