Anritsu Spectrum Master MS2720T - Audio Spectrum AM Menu

AM/FM/PM Analyzer (Option 509) 7-12 Audio Spectrum AM Menu
Spectrum Analyzer MG PN: 10580-00349 Rev. H 7-19
7-12 Audio Spectrum AM Menu
Key Sequence: Measure or (Shift + 4) > Audio Spectrum > Audio Spectrum
Span: Press to set the span for the AM audio spectrum display. Use the
numeric keypad, the rotary knob, or the arrow keys to set the value. Valid
values are 2 kHz, 5 kHz, 10 kHz, 20 kHz, 70 kHz, and 140 kHz.
Squelch Power: Press to set the squelch power level.
Back: Press to return to the Measurements menu.
Figure 7-16. Audio Spectrum AM Menu
Back
Span
## Hz
Squelch Power
### dBm
Audio Spectrum
AM
