TD-SCDMA/HSPA+ Signal Analyzer 4-11 Measurements Menu
3GPP MG PN: 10580-00234 Rev. T 4-21
4-11 Measurements Menu
Key Sequence: Measurements
RF Measurements: Press this submenu key to display the
“RF Measurements Menu” on page 4-22.
Demodulator: Press this submenu key to display the “Demodulator Menu”
on page 4-24 and to set up demodulator testing.
OTA: Press this submenu key to display the “Over-The-Air Menu” on
page 4-25.
Pass Fail Mode: Press this submenu key to activate the Pass/Fail test.
Press this submenu key again to display the “Pass Fail Mode Menu” on
page 4-26 and set up pass/fail testing.
TD-SCDMA Summary: Press this submenu key to display a table of the
TD-SCDMA measurements. The following measurement values are
displayed in the table:
Channel Power
Occ BW
Slot Power
DwPTS Power
UpPTS Power
On/Off Ratio
Freq Error
Freq Error PPM
EVM
Peak CDE
Tau
Save Measurement: Press this submenu key to save a measurement. You
may accept the default filename or enter your own filename. Refer to your
instrument’s User Guide for information on file management functions.
Figure 4-20. TD-SCDMA/HSPA+ Measurements Menu
Measurements
RF Measurements
Pass
Fail
Mode
TD-SCDMA
Summary
Save
Measurement
OTA
Demodulator
