4-11 Measurements Menu TD-SCDMA/HSPA+ Signal Analyzer
4-22 PN: 10580-00234 Rev. T 3GPP MG
RF Measurements Menu
Key Sequence: Measurements > RF Measurements
Channel Spectrum: Displays the spectrum of the input signal. The span is
automatically set to 5 MHz. Beneath the graph, values for the following
measurements are displayed: Left Channel Power, Channel Power, Right
Channel Power, Left Channel Occ BW, Occ BW, and Right Channel Occ
BW. Channel Power is displayed in dBm or watts depending on unit
selection.
Power vs. Time: Opens the “Power vs. Time Menu” on page 4-23.
Spectrum Emission: Changes the display for Spectrum Emission
measurement.
RF Summary: Press this submenu key to display the following RF
measurements in table format:
Channel Power
Channel Power (RRC)
Occ BW
DwPTS Pwr
UpPTS Pwr
On/Off Ratio
Slot PAR
Left Channel Power
Right Channel Power
Left Channel Occ BW
Right Channel Occ BW
Back: Press this submenu key to return to “Measurements Menu” on
page 4-21.
Figure 4-21. TD-SCDMA/HSPA+ RF Measurement Menu
RF Measurements
Channel
Spectrum
Power vs. Time
Back
RF
Summary
Spectrum Emission
