TD-SCDMA/HSPA+ Signal Analyzer 4-11 Measurements Menu
3GPP MG PN: 10580-00234 Rev. T 4-23
Power vs. Time Menu
Key Sequence: Measurements > RF Measurements > Power vs. Time
View: Press this submenu key to display the Power vs. Time graph in
either the Sub-Frame view or the Slot view.
Slot Selection: Press this submenu key to display the Slot Selection
menu and open the Slot Selection window. Use the rotary knob or press
the touch screen to highlight the desired slot (0 to 6), then press Enter. If
Auto is selected, the active slot will be detected automatically.
Auto: Automatically looks for an active downlink slot. Auto in the
Slot Selection window and the Auto submenu key have the same
function.
Cancel: Cancels any new setting you have highlighted without
pressing Enter. If the Slot Selection currently in effect is
highlighted, returns to the Power vs. Time menu.
Mask: Press this submenu key to turn the mask On and Off.
Back: Press this submenu key to return to the “Measurements Menu” on
page 4-21.
Figure 4-22. TD-SCDMA/HSPA+ Power vs. Time Menu
Back
Power vs. Time
View
Sub-Frame Slot
Slot Selection
Cancel
Slot Selection
Auto
Mask
Off On
