TD-LTE Signal Analyzer 6-12 Measurements Menu
3GPP MG PN: 10580-00234 Rev. T 6-41
Over-the-Air Menu
Key Sequence: Measurements > Over-the-Air
Scanner: Press this submenu key to display the Scanner table, which
shows several power measurements for multiple base stations at the same
frequency. Measurements include Sync Signal (S-SS) Power, RSRP,
RSRQ, and SINR. Press the key again to display the “OTA Scanner Menu”
on page 6-42 to set up Sort By and Show Mod Results.
Tx Test: Opens the OTA Tx Test mode. Press it again to open the
“Over-the-Air Tx Test Menu” on page 6-43 and the Show Mod Results
submenu key.
Mapping: Sets the display for coverage mapping. Press it again to set the
coverage mapping parameters – Save/Recall Points/Map, Measurement
Setup and Point Distance/Time Setup.
For full details, refer to Chapter 7, “LTE and TD-LTE Coverage Mapping”.
Carrier Aggregation: Press this submenu key to display the Carrier
Aggregation Component Carrier frequencies and measured parameters. In
the Carrier Aggregation Menu, select the desired Component Carrier to set
up for measurement. Refer to “Carrier Aggregation Menu” on page 6-45.
EMF (Option 444 only): When first selected, this submenu key enables the
EMF Measurement mode. Once the EMF Measurement mode is active,
this button opens the “LTE/TD-LTE EMF Menu” on page 8-2.
Back: Press this submenu key to return to the “Measurements Menu” on
page 6-33.
Figure 6-35. TD-LTE Over-the-Air Menu
Over-the-Air
Scanner
Tx Test
Mapping
Back
EMF
Carrier
Aggregation
