8-3 LTE/TD-LTE EMF Menu EMF (Option 444)
8-4 PN: 10580-00234 Rev. T 3GPP MG
RS Display Menu
Key Sequence: Measurements > Over-the-Air > EMF > Measurement Parameters >
RS Meas Display
The displayed Reference Signal parameters below can be changed at the
start or at the end of the measurement cycle. All of the parameters are always
computed and stored. Once the measurement is complete, any combination
of parameters can be viewed (three at a time and in any one of the desired
units).
RS Act: Selects the display of Actual Value (current isotropic number).
RS Total Min: Selects the display of Total Min, which is the minimum value for
the entire measurement period (Measurement Time × Number of
Measurements).
RS Total Max: Selects the display of Total Max, which is the maximum value
for the entire measurement period.
RS Avg/Meas: Selects the display of Avg/Meas, which is the running average
for the current Measurement Time. This is the default selection.
RS Total Avg: Selects the display of Total Avg, which is the running average
for the entire measurement period.
Back: Returns to the “Meas Params Menu (LTE/TD-LTE)” on page 8-3.
Figure 8-4. RS Display Menu
RS Display
RS Act
Back
RS Total Min
RS Total Max
RS Total Avg
RS Avg/Meas
