Anritsu Spectrum Master MS2720T User Manual

EMF (Option 444) 8-3 LTE/TD-LTE EMF Menu
3GPP MG PN: 10580-00234 Rev. T 8-3
Meas Params Menu (LTE/TD-LTE)
Key Sequence: Measurements > Over-the-Air > EMF > Measurement Parameters
RS Meas Display: Opens the “RS Display Menu” on page 8-4.
P-SS Meas Display: Opens the “P-SS Display Menu” on page 8-5.
S-SS Meas Display: Opens the “S-SS Display Menu” on page 8-6.
Extr Factor On/Off: Toggles On/Off the Extrapolation Factor. The
extrapolation factor, if turned On, displays the extrapolated field strength
number for the selected capture bandwidth.
Back: Returns to the “LTE/TD-LTE EMF Menu” on page 8-2.
Figure 8-3. LTE/TD-LTE Meas Params Menu
Meas Params
Extr Factor
On Off
S-SS Meas
Display
P-SS Meas
Display
RS Meas
Display
Back
