8-3 LTE/TD-LTE EMF Menu EMF (Option 444)
8-6 PN: 10580-00234 Rev. T 3GPP MG
S-SS Display Menu
Key Sequence: Measurements > Over-the-Air > EMF > Measurement Parameters >
S-SS Meas Display
The displayed Secondary Synchronization Signal parameters below can
be changed at the start or at the end of the measurement cycle. All the
parameters are always computed and stored. Once the measurement is
complete, any combination of parameters can be viewed (three at a time and
in any one of the desired units).
S-SS Act: Selects the display of Actual Value (current isotropic number).
S-SS Total Min: Selects the display of Total Min, which is the minimum value
for the entire measurement period (Measurement Time × Number of
Measurements).
S-SS Total Max: Selects the display of Total Max, which is the maximum
value for the entire measurement period.
S-SS Avg/Meas: Selects the display of Avg/Meas, which is the running
average for the current Measurement Time. This is the default selection.
S-SS Total Avg: Selects the display of Total Avg, which is the running
average for the entire measurement period.
Back: Returns to the “Meas Params Menu (LTE/TD-LTE)” on page 8-3.
Figure 8-6. S-SS Display Menu
S-SS Display
S-SS Act
Back
S-SS Total Min
S-SS Total Max
S-SS Total Avg
S-SS Avg/Meas
