2-12 Setup Menu
Key Sequence: Setup
PN Setup: Opens the “PN Setup Menu” on page 2-23.
Walsh Codes: Toggles between 64 codes and 128 codes.
Meas Speed: Toggles through “Fast”, “Norm” (normal), and “Slow”
measuring speed.
Ext Trig Polarity: Toggles between Rising edge and Falling edge trigger
polarity.
Number of Carriers: This submenu key sets the number of required
channels. This affects the ACPR and Spurious Emissions measurements.
Carrier BW: This submenu key sets the carrier bandwidth. It rotates
between 1.23, 1.24 and 1.25.
Figure 2-16. CDMA Setup Menu
Setup
PN Setup
Walsh Codes
64 128
Meas Speed
Fast Norm Slow
Ext Trig Polarity
Rising Falling
Number of Carriers
1
Carrier BW (MHz)
1.23 1.24 1.25
