3-13 Setup Menu EVDO Signal Analyzer
3-24 PN: 10580-00235 Rev. D 3GPP2 MG
PN Setup Menu
Key Sequence: Setup > PN Setup
PN Trigger: This submenu key toggles through “No Trig” (no trigger), “GPS”,
and “Ext” (external trigger).
PN Search Type: This submenu key toggles between “Auto” and “Manual”
PN search. In the Auto mode, the instrument automatically searches for the
strongest PN. When using manual setup, enter the required PN offset to limit
the search. Auto search is available only when the trigger selection is GPS
or External. If “No Trig” is selected, then pressing this submenu key causes
an error message to be displayed, stating “Applicable only when PN Type is
GPS or External”.
Manual PN Offset: Press this submenu key to manually set the PN offset.
Use the arrow keys, rotary knob, or numeric keypad to choose an offset,
then press the rotary knob or the Enter key to select the value. Editing this
value automatically changes the PN Search Type to Manual.
The Manual PN Offset function is available only when the trigger selection is
GPS or External. If “No Trig” is selected, then pressing this submenu key
causes an error message to be displayed, stating “Applicable only when PN
Type is GPS or External”.
Back: Returns to the “Setup Menu” on page 3-23.
Figure 3-19. EVDO PN Setup Menu
PN Trigger
No Trig GPS Ext
Back
PN Search Type
Auto Manual
Manual PN Offset
N/A
