Model 101/2100 Doors Service & Installation
TITLE:
99-13312-S001 Model 101/2100 Doors Service &
Installation
6. Set frame in net opening. For safety, partially install wood screws in top of frame. Do
not tighten. Torquemaster (silver rectangular box) goes at bottom of frame; hinge pin
to top of frame.
7. Check frame for square, as shown. Shim as necessary. Ensure that shims are placed
as close to installation holes as possible. When shimming is necessary, shim top and
bottom and/or left end of frame and right end of frame to maintain square of frame in
net opening.
Continuous Lineup Frames:
8. Set next frame into case opening and snug frame against right side of first frame.
9. Square and plumb second frame. For safety, partially install wood screws in top of
frame.
10. Insert sex bolts through right side of first frame, into left side of second frame.
Tighten until frames are pulled together.
11. From inside of case, caulk all four sides of frame, between frame and opening.
12. Starting with frame sill, install mounting screws and tighten, then do sides and top.
Do not over-tighten top screws, as this will bow frame.
13. From inside the case, re-check caulking.
6. Frame Divider Board Installation (Prior to 1993)
Instructions are for multiple full flange frame lineups.
Frames are shipped with divider board taped to end of frame.
Divider board is pre-cut to given net opening height. For example, a 75” net opening will
get a 75” divider board, and a 67” net opening will get a 67” divider board.
If net opening height varies, make up the difference with a solid shim.
1. Set frame into case opening and push frame tight against left side of opening. Square
and plumb frame. Install installation screws on bottom of frame, left end of frame and
top of frame.
2. Insert divider board behind flange on right side of frame. Toenail divider board to sill
and header, if possible. (Metal cover plate is on customer side.) Screw right end of
frame to divider board.
3. Set next frame into net opening and snug frame against divider board. Install screws
through left side of frame into divider board.
4. When adding divider boards and frame sections, always make sure frames are plumb
and square.
5. Continue adding frames and divider boards to complete line-up.
6. Divider boards must be snug between sill and header.
