Model 101/2100 Doors Service & Installation
TITLE:
99-13312-S001 Model 101/2100 Doors Service & Installation
REV.
B
Page 76 of 95
70. Heat Load in BTU/Hr for Model 101 Low Temp Glass, Door Rail,
Frame Heaters and Standard Lighting
(Per Door, with Doors Closed @ 75°F Store Ambient)
MODEL 101 LOW TEMPERATURE
(3-PANE HEATED REFLECTIVE GLASS – CASE TEMP -10°F)
DOOR SIZE
1 DOOR
2 DOOR
3 DOOR
4 DOOR
5 DOOR
24 x 36 874 1448 2022 2596 3170
24 x 67 1061 1821 2582 3343 4104
24 x 75 1112 1924 2736 3548 4360
26 x 67 1094 1887 2681 3475 4268
26 x 75 1145 1990 2835 3680 4525
28 x 75 1182 2064 2946 3828 4710
28 x 79 1207 2113 3020 3927 4834
30 x 36 932 1564 2196 2828 3460
30 x 67 1155 2009 2864 3718 4573
30 x 75 1212 2124 3036 3948 4860
30 x 79 1241 2183 3124 4065 5006
NOTE:
Add 10-20% to above values depending on door opening frequency.
71. Heat Load in BTU/Hr for Model 101 Normal Temp Glass, Door Rail,
Frame Heaters and Standard Lighting
(Per Door, with Doors Closed @ 75°F Store Ambient)
MODEL 101 NORMAL TEMPERATURE
(2-PANE NON-HEATED GLASS – CASE TEMP 38°F)
DOOR SIZE
1 DOOR
2 DOOR
3 DOOR
4 DOOR
5 DOOR
24 x 36
586
948
1309
1670
2031
24 x 67
692
1159
1627
2094
2561
24 x 75
720
1214
1709
2203
2698
26 x 67
709
1194
1678
2162
2646
26 x 75
739
1252
1766
2279
2793
28 x 75
758
1290
1823
2355
2888
28 x 79
773
1321
1869
2417
2965
30 x 36
615
1006
1396
1787
2177
30 x 67
743
1262
1780
2299
2817
30 x 75
777
1328
1880
2431
2983
30 x 79
793
1361
1929
2497
3065
