Model 101/2100 Doors Service & Installation
TITLE:
99-13312-S001 Model 101/2100 Doors Service & Installation
REV.
B
Page 75 of 95
11 12 13 14 15 16 17 18 19 20
AMPS PER
LIGHT
24 x 36
5.00
5.46
5.90
6.36
6.81
7.28
7.73
8.17
8.63
9.08
0.46
24 x 67
7.65
8.34
9.05
9.74
10.44
11.12
11.82
12.53
13.22
13.92
0.55
24 x 75
8.38
9.15
9.90
10.67
11.43
12.20
12.96
13.71
14.48
15.24
0.55
26 x 67
7.84
8.55
9.28
9.99
10.71
11.40
12.12
12.85
13.56
14.28
0.55
26 x 75
8.88
9.69
10.48
11.29
12.09
12.92
13.72
14.51
15.32
16.12
0.55
28 x 75
9.07
9.90
10.71
11.54
12.36
13.20
14.02
14.83
15.66
16.48
0.55
28 x 79
9.48
10.35
11.18
12.05
12.90
13.80
14.65
15.48
16.35
17.20
0.55
30 x 36
5.72
6.24
6.78
7.30
7.83
8.32
8.85
9.39
9.91
10.44
0.46
30 x 67
8.50
9.27
10.04
10.81
11.58
12.36
13.13
13.90
14.67
15.44
0.55
30 x 75
8.94
9.75
10.56
11.37
12.18
13.00
13.81
14.62
15.43
16.24
0.55
30 x 79
9.35
10.20
11.05
11.90
12.75
13.60
14.45
15.30
16.15
17.00
0.55
11 12 13 14 15 16 17 18 19 20
AMPS PER
LIGHT
24 x 36
8.83
9.63
10.43
11.23
12.03
12.84
13.64
14.44
15.24
16.04
0.46
24 x 67
15.01
16.38
17.74
19.10
20.46
21.84
23.20
24.56
25.92
27.28
0.55
24 x 75
16.69
18.21
19.73
21.25
22.77
24.28
25.80
27.32
28.84
30.36
0.55
26 x 67
15.84
17.28
18.72
20.16
21.60
23.04
24.48
25.92
27.36
28.80
0.55
26 x 75
17.35
18.93
20.51
22.09
23.67
25.24
26.82
28.40
29.98
31.56
0.55
28 x 75
18.21
19.86
21.51
23.16
24.81
26.48
28.13
29.78
31.43
33.08
0.55
28 x 79
19.14
20.88
22.62
24.36
26.10
27.84
29.58
31.32
33.06
34.80
0.55
30 x 36
10.67
11.64
12.61
13.58
14.55
15.52
16.49
17.46
18.43
19.40
0.46
30 x 67
17.16
18.72
20.28
21.84
23.40
24.96
26.52
28.08
29.64
31.20
0.55
30 x 75
18.78
20.49
22.20
23.91
25.62
27.32
29.03
30.74
32.45
34.16
0.55
30 x 79
19.66
21.45
23.22
25.01
26.79
28.60
30.38
32.15
33.94
35.72
0.55
NOTES: 3. When calculating standard lamp amperage, add 1 lamp to the number of doors in the line-up and
multiply that number by the appropriate AMPS PER LIGHT value.
4. Design parameters do not make allowances for factors such as air leaks or unusual air flow
patterns within cases; therefore, some sweating may occur when upper limits of temperature or
humidity are encountered.
