Model 101/2100 Doors Service & Installation
TITLE:
99-13312-S001 Model 101/2100 Doors Service &
Installation
Contents:
1. Models 101 & 2100 Door & Frame – Reversible Parts Placement (Start 10/89) ...................6
2. Models 101 & 2100 Reversible Door Parts Placement (1989 to 1991) .................................7
3. Models 101 & 2100 Standard (Before 7/94) Frame Net Opening Widths..............................8
3.1.1. 24” Door (Catalog Size) 23-3/16” Actual Door Width ............................................. 8
3.1.2. 26” Door (Catalog Size) 26-3/8” Actual Door Width ............................................... 8
3.1.3. 30” Door (Catalog Size) 29-7/8” Actual Door Width ............................................... 8
4. Models 101 & 2100 Standard Frame Net Opening Heights ..................................................9
5. Models 101 & 2100 Frame Installation ..................................................................................9
6. Frame Divider Board Installation (Prior to 1993) .................................................................10
7. Reversible/Cordless Door & Hold-Open Installation............................................................11
8. Reversing Frame Hardware ................................................................................................12
9. Door Reversing Instructions Models 101 & 2100 (1989-1991)............................................13
10. Door Reversing Instructions (1991 to Present) ...................................................................16
11. Models 103, 105, 107, 2125, 2127 & 2130 Pass-Thru Installation ......................................17
12. Frame Sill Plastic protector Installation Models 101 & 2100................................................19
13. Contact Plate and Contact Plate Retainer Replacement.....................................................20
14. Ordering Replacement Doors..............................................................................................21
15. Torquemaster Replacement ................................................................................................22
16. Door Gasket Replacement ..................................................................................................22
17. Door Plastic (Cover) Replacement ......................................................................................23
18. Door Cut-Away & Handle Replacement ..............................................................................23
19. Side Access Plate Replacement (1989 to 1991) .................................................................24
20. Side Access Plate Replacement (1991 to Present).............................................................24
21. Door Female Plug Replacement (1989 to 1991) .................................................................25
22. Frame Female Plug and/or Socket Replacement (1991 to Present) ...................................25
23. Door Heater Replacement (1989 to 1991) Model 101 Only ................................................26
24. Door Heater Replacement (1991 to Present) Model 101 Only ............................................26
25. Hinge Pin Replacement (1989 to 1991) ..............................................................................27
26. Hinge Pin Replacement (1991 to Present) ..........................................................................27
