36. Frame Heater Wire Replacement
1. Remove door from frame, following previous instructions for door removal.
2. Insert small flat-head screwdriver under back side edge of contact plate retainer and lift
up to remove.
Mullion Front
and Retainer
3. Remove contact plate to expose heater wires.
4. See following page for frame heater schematics.
5. Cut heater at the lead wire and pull heater out of track.
