4. If glass is heated, unplug Black and White solid wires from glass.
5. Heater wire lies in track on the back outside edge of door. Pull heater out.
6. Reverse instructions to replace door heater. Plug in Black or Red lead wire from hinge
pin to Black or Red lead wire from heater, White lead wire from hinge pin to White
heater lead and Green/Yellow lead from hinge pin to ground.
Note: If glass is heated, plug in Black and White lead wires coming off heater loom to
Black and White lead wires from glass.
7. Replace side access plate.
8. Replace door plastic and gasket.
25. Hinge Pin Replacement (1989 to 1991)
1. Model 101 - Remove top side access plate (Door Cut-Away).
Note: Lead Wires: Heater (Black, White), Receptacle (Black, White, Green), Glass
(Black, White).
2. Unsnap female receptacle from hinge pin and remove hinge pin out through top door
rail.
3. Reverse instructions to replace.
26. Hinge Pin Replacement (1991 to Present)
1. Model 101 & 2100 - Remove center hinge side access plate (Door Quick Disconnect and
Reversing
).
2. Unplug Black or Red lead wire from hinge pin from Black solid heater wire lead.
3. Unplug White lead wire from hinge pin from White solid heater wire lead.
4. Unplug Green/Yellow (ground) lead wire.
5. If glass is heated, unplug Black and White lead wire on heater loom from Black and
White lead wire from glass.
6. Pull hinge pin out through top of door.
7. Reverse instructions to replace.
27. Wiring Instructions, Heated & Non-Heated Glass (1991 to Present)
1. Heated Glass – Connect Black or Red lead wire from hinge pin to Black lead wire from
glass and Red or Black lead wire from door heater (Door Quick Disconnect and Reversing).
2. Connect White heater lead wire from hinge pin to glass White lead wire.
3. Non-Heated Glass – Connect Black or Red lead wire from hinge pin to Black or Red
door heater lead.
4. Connect White lead wire from hinge pin to White door heater lead.
