77. Electrical Information for Model 101 Low Temp Doors,
Frames & “ELS Electronic Lighting System
Heater Amperages @ 120 Volts
NUMBER OF DOORS:
1
2
3
4
5
6
7
8
9
10
STYLE:
Low temp doors with heaters, 3-Pane Heated Reflective Glass (5.75 W/SQ. FT.)
APPLICATION:
Case Temperature -10°F, Humidity 75% or less @ 75°F ambient.
24 x 36
1.12
2.20
3.27
4.26
5.33
6.54
7.53
8.52
9.59
10.66
24 x 67
1.86
3.40
4.98
6.59
8.21
9.96
11.57
13.18
14.80
16.42
24 x 75
2.00
3.68
5.43
7.24
9.03
10.86
12.67
14.48
16.27
18.06
26 x 67
1.91
3.74
5.44
7.23
8.93
10.88
12.67
14.46
16.16
17.86
26 x 75
2.13
4.05
5.89
7.72
9.67
11.78
13.61
15.44
17.39
19.34
28 x 75
2.18
4.15
6.20
8.16
10.19
12.40
14.36
16.32
18.35
20.38
28 x 79
2.41
4.39
6.52
8.59
10.75
13.04
15.11
17.18
19.34
21.50
30 x 36
1.34
2.68
3.95
5.32
6.49
7.90
9.27
10.64
11.81
12.98
30 x 67
2.10
3.98
5.80
7.78
9.57
11.60
13.58
15.56
17.35
19.14
30 x 75
2.29
4.32
6.36
8.41
10.41
12.72
14.77
16.82
18.82
20.80
30 x 79
2.42
4.56
6.66
8.90
10.98
13.32
15.56
17.80
19.88
21.96
NOTES: 1. All amperages are design amperages subject to the following tolerances: heated glass +/- 8%.
2. Although the amperages are calculated at 120 volts, all doors are designed to operate without
sweating when used within the application parameters with a voltage range of +/- 10%.
3. Design parameters do not make allowances for factors such as air leaks or unusual air flow
patterns within cases; therefore, some sweating may occur when upper limits of temperature or
humidity are encountered.
4. See following chart for calculating additional Light Amperage for “ELS” Electronic Lighting:
“ELS” Lighting System 120 Volt Light Amperage (per frame section)
No. Doors:
1
2
3
4
5
No. “ELS” Lights:
2
3
4
5
6
LAMPS LENGTH
TOTAL AMPS
48”
0.92
1.45
1.84
2.37
2.76
60”
1.30
2.02
2.60
3.32
3.90
72”
1.31
2.07
2.62
3.38
3.93
.
