ANthony 103 - Reversible;Cordless Door & Hold-Open Installation

Model 101/2100 Doors Service & Installation
TITLE:
99-13312-S001 Model 101/2100 Doors Service & Installation
REV.
B
Page 11 of 95
7. Reversible/Cordless Door & Hold-Open Installation
Model 101 and 2100 Hold-Open
Instructions
Note: Replace spare shoulder screw (#2) in spare box housing nut (#4) when
installing or reversing a door.
1. Align door with torque rod and insert into the Torquemaster socket at base of door.
2. Engage door with hinge pin plug inserted into hinge pin plug receptacle at top of
frame.
