ANthony 103 - And Standard Lights (Per Door, with Doors Closed @ 75°F Store Ambient)

Model 101/2100 Doors Service & Installation
TITLE:
99-13312-S001 Model 101/2100 Doors Service & Installation
REV.
B
Page 81 of 95
11 12 13 14 15 16 17 18 19 20
AMPS PER
LIGHT
24 x 36
2.97
3.24
3.51
3.78
4.05
4.32
4.59
4.86
5.13
5.40
0.46
24 x 67
4.62
5.04
5.46
5.88
6.30
6.72
7.14
7.56
7.98
8.40
0.55
24 x 75
5.03
5.49
5.95
6.41
6.87
7.32
7.78
8.24
8.70
9.16
0.55
26 x 67
4.70
5.13
5.56
5.99
6.42
6.84
7.27
7.70
8.13
8.56
0.55
26 x 75
5.20
5.67
6.15
6.63
7.11
7.56
8.04
8.52
9.00
9.48
0.55
28 x 75
5.47
5.97
6.45
6.95
7.44
7.96
8.45
8.93
9.43
9.92
0.55
28 x 79
5.67
6.18
6.71
7.22
7.74
8.24
8.76
9.29
9.80
10.32
0.55
30 x 36
3.44
3.75
4.06
4.37
4.69
5.00
5.31
5.62
5.93
6.25
0.46
30 x 67
5.11
5.58
6.04
6.50
6.97
7.44
7.90
8.36
8.82
9.30
0.55
30 x 75
5.39
5.88
6.37
6.86
7.35
7.84
8.33
8.82
9.31
9.80
0.55
30 x 79
5.58
6.09
6.60
7.11
7.62
8.12
8.63
9.14
9.65
10.16
0.55
11 12 13 14 15 16 17 18 19 20
AMPS PER
LIGHT
24 x 36
1.90 2.07 2.25 2.43 2.61 2.76 2.94 3.12 3.30 3.48 0.46
24 x 67
2.92 3.18 3.45 3.72 3.99 4.24 4.51 4.78 5.05 5.32 0.55
24 x 75
3.22 3.51 3.81 4.11 4.41 4.68 4.98 5.28 5.58 5.88 0.55
26 x 67
3.03 3.30 3.58 3.86 4.14 4.40 4.68 4.96 5.24 5.52 0.55
26 x 75
3.13 3.42 3.70 3.98 4.26 4.56 4.84 5.12 5.40 5.68 0.55
30 x 36
2.18 2.37 2.57 2.77 2.97 3.16 3.36 3.56 3.76 3.95 0.46
30 x 67
3.27 3.57 3.87 4.17 4.46 4.76 5.06 5.36 5.66 5.95 0.55
30 x 75
3.44 3.75 4.06 4.37 4.69 5.00 5.31 5.62 5.93 6.25 0.55
75. Heat Load in BTU/Hr for Model 2100 Normal Temp Glass, Door Rail,
Frame Heaters and Standard Lights
(Per Door, with Doors Closed @ 75°F Store Ambient)
MODEL 2100 NORMAL TEMPERATURE
(3-PANE NON-HEATED GLASS – CASE TEMP 38°F) – STANDARD PRODUCT
DOOR SIZE
1 DOOR
2 DOOR
3 DOOR
4 DOOR
5 DOOR
24 x 36
557
888
1220
1551
1883
24 x 67
637
1049
1460
1872
2284
24 x 75
658
1090
1523
1955
2388
26 x 67
649
1074
1498
1922
2347
26 x 75
671
1118
1564
2011
2457
28 x 75
685
1145
1606
2066
2526
28 x 79
697
1169
1641
2113
2585
30 x 36
578
931
1285
1638
1991
30 x 67
674
1123
1573
2022
2471
30 x 75
699
1173
1647
2121
2595
30 x 79
711
1198
1684
2171
2657
