2. Models 101 & 2100 Reversible Door Parts Placement (1989 to 1991)
Changes: 1991 to Present
1. Hinge Rail is hollow.
2. Use #17 Hinge Pin; replaces #9.
3. Delete #10 Receptacle.
4. Use #18 Torque Rod; replaces #12
5. Single hinge side Access Hole in center of Hinge Rail only. Delete #11.
Description
Description
Description
1. Corner Piece
7. Gasket
13. Cap
2. Corner Screw
8. Camel Back
14. Access Tube
3. Glazing Channel
9. Hinge Pin
15. Handle
4. Heater Wire
10. Receptacle
16. Handle Screw
5. Door Rail
11. Cover
17. Molded Hinge Pin
6. Plastic
12. Torque Rod
18. Torque Rod
