Model 101/2100 Doors Service & Installation
TITLE:
99-13312-S001 Model 101/2100 Doors Service &
Installation
REV.
B
Page 73 of 95
69. Electrical Information for Model 101 Normal Temp Heated Doors,
Frames & Standard Light Fixtures
Heater Amperages @ 120 Volts
NUMBER OF DOORS:
1
2
3
4
5
6
7
8
9
10
STYLE:
Normal temp doors with heaters, 2-Pane Non-Heated Glass
APPLICATION:
Case Temperature 38°F, Humidity 65% or less, @ 75°F ambient.
24 x 36
0.27
0.55
0.82
1.09
1.36
1.64
1.91
2.18
2.45
2.72
24 x 67
0.43
0.86
1.30
1.73
2.16
2.60
3.03
3.46
3.89
4.32
24 x 75
0.46
0.92
1.39
1.85
2.31
2.78
3.24
3.70
4.16
4.62
26 x 67
0.44
0.87
1.31
1.74
2.18
2.62
3.05
3.48
3.92
4.36
26 x 75
0.47
0.93
1.40
1.87
2.34
2.80
3.27
3.74
4.21
4.68
28 x 75
0.50
0.99
1.49
1.99
2.48
2.98
3.48
3.98
4.47
4.96
28 x 79
0.49
0.97
1.46
1.95
2.43
2.92
3.41
3.90
4.38
4.86
30 x 36
0.31
0.62
0.92
1.23
1.54
1.84
2.15
2.46
2.77
3.08
30 x 67
0.47
0.94
1.40
1.87
2.34
2.80
3.27
3.74
4.21
4.68
30 x 75
0.49
0.98
1.47
1.96
2.45
2.94
3.43
3.92
4.41
4.90
30 x 79
0.53
1.05
1.58
2.10
2.63
3.16
3.68
4.20
4.73
5.26
NUMBER OF DOORS:
1
2
3
4
5
6
7
8
9
10
STYLE:
Normal temp doors with heaters, 3-Pane Non-Heated Glass or 2-Pane Reflective NHG
APPLICATION:
Case Temperature 33°F, Humidity 68% or less, @ 75°F ambient.
24 x 36
0.45
0.91
1.36
1.82
2.27
2.72
3.18
3.64
4.09
4.54
24 x 67
0.70
1.39
2.09
2.78
3.48
4.18
4.87
5.56
6.26
6.96
24 x 75
0.76
1.52
2.28
3.05
3.81
4.56
5.33
6.10
6.86
7.62
26 x 67
0.71
1.43
2.14
2.85
3.57
4.28
4.99
5.70
6.42
7.14
26 x 75
0.81
1.61
2.42
3.23
4.03
4.84
5.65
6.46
7.26
8.06
28 x 75
0.82
1.64
2.47
3.30
4.12
4.94
5.77
6.60
7.42
8.24
28 x 79
0.86
1.72
2.58
3.45
4.30
5.16
6.03
6.90
7.75
8.60
30 x 36
0.52
1.04
1.56
2.08
2.61
3.12
3.64
4.16
4.69
5.22
30 x 67
0.77
1.54
2.32
3.09
3.86
4.64
5.41
6.18
6.05
7.72
30 x 75
0.81
1.62
2.44
3.25
4.06
4.88
5.69
6.50
7.31
8.12
30 x 79
0.85
1.70
2.55
3.40
4.25
5.10
5.95
6.80
7.65
8.50
