Anybus CompactCom 40 EtherNet/IP
Doc.Rev. 1.5
Chapter 1
1. About the Anybus CompactCom 40 EtherNet/IP
1.1 General
The Anybus CompactCom 40 EtherNet/IP communication module provides instant Ethernet and Eth-
erNet/IP connectivity via the patented Anybus CompactCom host interface. Any device that supports
this standard can take advantage of the features offered by the module, allowing seamless network inte-
gration regardless of network type. The module supports both linear and ring network topology (DLR,
Device Level Ring).
The modular approach of the Anybus CompactCom 40 platform allows the CIP-object implementation
to be extended to fit specific application requirements. Furthermore, the Identity Object can be custom-
ized, allowing the end product to appear as a vendor-specific implementation rather than a generic An-
ybus module.
This product conforms to all aspects of the host interface for Anybus CompactCom 40 modules defined
in the Anybus CompactCom 40 Hardware and Software Design Guides, making it fully interchangeable
with any other device following that specification. Generally, no additional network related software
support is needed, however in order to be able to take full advantage of advanced network specific func-
tionality, a certain degree of dedicated software support may be necessary.
1.2 Features
• Two EtherNet/IP ports
• Ethernet RJ45 connectors
• Beacon Based DLR (Device Level Ring) and linear network topology supported
• Black channel interface, offering a transparent channel supporting Functional Safety up to SIL3
with separate safety module
1
• 10/100 Mbit, full/half duplex operation
• Web server w. customizable content
•FTP server
• Email client
• Server Side Include (SSI) functionality
• JSON functionality
• Customizable Identity Information
• Up to 65535 ADIs
• CIP Parameter Object support
• Expandable CIP-object implementation
• Supports unconnected CIP routing
• Transparent Socket Interface
• Modular Device functionality
• QuickConnect supported
• Multiple IO assembly instances can be created
1. IXXAT Safe T100 recommended
