Doc.Id. HMSI-27-212

Anybus CompactCom 40 EtherNet/IP

Doc.Rev. 1.5

9.5 Network Configuration Object (04h)

Category

Extended

Object Description

This object holds network specific configuration parameters that may be set by the end user. A reset

command (factory default) issued towards this object will result in all instances being set to their default

values.

If the settings in this object do not match the configuration used, the Module Status LED will flash red

to indicate a minor error.

The object is described in further detail in the Anybus CompactCom 40 Software Design Guide.

See also...

• “Communication Settings” on page 16

• “TCP/IP Interface Object (F5h)” on page 87 (CIP-object)

• “Ethernet Link Object (F6h)” on page 90 (CIP-object)

• “E-mail Client” on page 32

Supported Commands

Object: Get_Attribute

Reset

Instance: Get_Attribute

Set_Attribute

Get_Enum_String

Object Attributes (Instance #0)

# Name Access Data Type Value

1 Name Get Array of CHAR ‘Network Configuration’

2 Revision Get UINT8 01h

3 Number of instances Get UINT16 000Fh (15)

4 Highest instance no. Get UINT16 0013h (19)
