8.14 TCP/IP Interface Object (F5h)
Category
Extended
Object Description
This object provides the mechanism to configure the TCP/IP network interface of the module. It
groups the TCP/IP-related settings in one instance for each TCP/IP capable communications interface.
See also...
• “Communication Settings” on page 16
• “Network Configuration Object (04h)” on page 99 (Anybus Module Object)
Supported Services
Class services: Get_Attribute_All
Get_Attribute_Single
Instance services: Get_Attribute_All
Get_Attribute_Single
Set_Attribute_Single
Class Attributes
# Name Access Type Value
1 Revision Get UINT 0004h (Object revision)
2 Max instance Get UINT 1 (Maximum instance number)
3 Number of
instances
Get UINT 1 (Number of instances)
6 Maximum ID
Number Class
Attributes
Get UINT 7 (The attribute number of the last implemented class attribute)
7 Maximum ID
Number
Instance Attrib-
utes
Get UINT 13 (The attribute number of the last implemented instance attribute)
