Anybus CompactCom 40 EtherNet/IP User Manual

CIP Objects 86
Doc.Id. HMSI-27-212
Anybus CompactCom 40 EtherNet/IP
Doc.Rev. 1.5
Instances Attributes (Instance #1)
Extended
This instance reflects the properties associated with the Ethernet interface.
See also...
• “CIP Port Configuration Object (0Dh)” on page 153
Instances Attributes (Instances #2... #8)
Extended
See also...
• “CIP Port Configuration Object (0Dh)” on page 153 ( “Instance Attributes” on page 154)
# Name Access Type Value
1 Port Type Get UINT 0h (default)
4h (if the application registers a port)
2 Port Number Get UINT 2h
3 Link Object Get Struct of:
UINT
Padded EPATH
-
2h (Path Length)
20 F5 24 01h (Link Path)
4 Port Name Get SHORT_STRING “EtherNet/IP”
5 Port Type Name Get SHORT_STRING “”
6 Port Description Get SHORT_STRING “”
7 Node Address Get Padded EPATH -
# Name Access Type Value
1 Port Type Get UINT Enumerates the type of port
2 Port Number Get UINT CIP port number associated with this port
3 Link Object Get Struct of:
UINT
Padded EPATH
-
Path length (number of 16-bit words)
Logical path segments which identify the object for this port.
The path must consist of one logical class segment and one
logical instance segment. The maximum size is 12 bytes.
4 Port Name Get SHORT_STRING Name of port, e.g. “Port A”. Max. 64 characters.
5 Port Type Name Get SHORT_STRING “”
6 Port Description Get SHORT_STRING “”
7 Node Address Get Padded EPATH Node number of this device on port. The range within this data
type is restricted to a Port Segment.
8 Port Node Range Get Struct of:
UINT (Min.)
UINT (Max.)
-
Min. node number on port
Max. node number on port
