Anybus CompactCom 40 EtherNet/IP User Manual

96
Doc.Id. HMSI-27-212
Anybus CompactCom 40 EtherNet/IP
Doc.Rev. 1.5
9.2 Anybus Object (01h)
Category
Basic
Object Description
This object assembles all common Anybus data, and is described thoroughly in the general Anybus
CompactCom 40 Software Design Guide.
Supported Commands
Object: Get_Attribute
Instance: Get_Attribute
Set_Attribute
Get_Enum_String
Object Attributes (Instance #0)
(Consult the general Anybus CompactCom 40 Software Design Guide for further information.)
Instance Attributes (Instance #1)
Basic
Extended
# Name Access Type Value
1 Module type Get UINT16 0403h (Standard Anybus 40 CompactCom)
2... 11 - - - Consult the general Anybus CompactCom 40
Software Design Guide for further information.
12 LED colours Get struct of:
UINT8(LED1A)
UINT8(LED1B)
UINT8(LED2A)
UINT8(LED2B)
Value:
Colour:
01h Green
02h Red
01h Green
02h Red
13... 16 - - - Consult the general Anybus CompactCom 40
Software Design Guide for further information.
# Name Access Type Value
17 Virtual attributes Get/Set - Consult the general Anybus CompactCom 40
Software Design Guide for further information.
18 Black list/White list Get/Set
19 Network Time Get UINT64 Not used (Always 0)
