Anybus CompactCom 40 EtherNet/IP User Manual

148
Doc.Id. HMSI-27-212
Anybus CompactCom 40 EtherNet/IP
Doc.Rev. 1.5
9.9 Network Ethernet Object (0Ch)
Category
Extended
Object Description
This object provides ethernet-specific information to the application.
Supported Commands
Object: Get_Attribute
Instance: Get_Attribute
Object Attributes (Instance #0)
Instance Attributes (Instance #1)
Extended
# Name Access Data Type Value
1 Name Get Array of CHAR ‘Network Ethernet’
2 Revision Get UINT8 01h
3 Number of instances Get UINT16 -
4 Highest instance no. Get UINT16 -
# Name Access Type Description
1 MAC Address Get Array of UINT8 Current MAC address.
See also “Ethernet Host Object (F9h)” on page 171)

Anybus CompactCom 40 EtherNet/IP Specifications

General

Communication Protocol	EtherNet/IP
Form Factor	Compact
Protocol	Ethernet/IP
Data Rates	10/100 Mbps
Connector	RJ45
Certifications	CE, UL

Summary

Chapter 1 About the Anybus CompactCom 40 EtherNet/IP

1.2 Features

Lists the key features and functionalities offered by the module.

Chapter 2 Basic Operation

2.2 Device Customization

Details how to configure device identity, EDS files, and other settings.

2.3 Communication Settings

Explains TCP/IP and physical link settings for network communication.

2.4 Diagnostics

Describes how to access and interpret diagnostic information from the module.

2.5 Network Data Exchange

Covers application data, process data, and data type translation.

Chapter 4 Web Server

4.3 Server Configuration

Covers settings for the web server, including root directory and content types.

Chapter 6 Server Side Include (SSI)

6.3 Command Functions

Details various SSI command functions for interacting with the module.

Chapter 8 CIP Objects

8.3 Identity Object (01h)

Provides identification and general information about the module.

8.5 Assembly Object (04h)

Holds Process Data sent/received by the host application via static assemblies.

8.6 Connection Manager (06h)

Used for establishing and managing connections across subnets.

8.7 Parameter Object (0Fh)

Provides an interface to the module's configuration parameters.

8.12 ADI Object (A2h)

Maps instances in the Application Data Object to EtherNet/IP.

8.13 Port Object (F4h)

8.14 TCP/IP Interface Object (F5h)

Configures the TCP/IP network interface settings.

8.15 Ethernet Link Object (F6h)

Maintains link counters and status for IEEE 802.3 communications.

Chapter 9 Anybus Module Objects

9.3 Diagnostic Object (02h)

9.5 Network Configuration Object (04h)

Holds network-specific configuration parameters settable by the end user.

Chapter 10 Host Application Objects

10.2 Functional Safety Host Object (E8h)

Specifies safety settings and is mandatory if Functional Safety is supported.

10.3 CIP Identity Host Object (EDh)

10.2 EtherNet/IP Host Object (F8h)

Implements EtherNet/IP specific features in the host application.

10.3 Ethernet Host Object (F9h)

Implements Ethernet features in the host application.
