Anybus CompactCom 40 EtherNet/IP User Manual

JSON 55
Doc.Id. HMSI-27-212
Anybus CompactCom 40 EtherNet/IP
Doc.Rev. 1.5
7.2.3 Network
ethstatus.json
GET network/ethstatus.json.
“comm2” is not present if Ethernet port 2 is inactivated.
Comm Object Definition:
JSON object layout:
{
"mac": "003011FF0201",
"comm1": {
"link": 1,
"speed": 1,
"duplex": 1
}
"comm2": {
"link": 0,
"speed": 0,
"duplex": 0
}
}
Name Data Type Note
mac String 6 byte hex
comm1 Object See object definition in the table below
comm2 Object See object definition in the table below
Name Data Type Note
link Number 0: No link
1: Link
speed Number 0: 10 Mbit
1: 100 Mbit
duplex Number 0: Half
1: Full
