Anybus CompactCom 40 EtherNet/IP User Manual

CIP Objects 78
Doc.Id. HMSI-27-212
Anybus CompactCom 40 EtherNet/IP
Doc.Rev. 1.5
8.9 QoS Object (48h)
Category
Extended
Object Description
Quality of Service (QoS) is a general term that is applied to mechanisms used to treat traffic streams with
different relative priorities or other delivery characteristics. Standard QoS mechanisms include IEEE
802.1D/Q (Ethernet frame priority) and Differentiated Services (DiffServ) in the TCP/IP protocol
suite.
The QoS Object provides a means to configure certain QoS related behaviors in EtherNet/IP devices.
The object is required for devices that support sending EtherNet/IP messages with nonzero DiffServ
code points (DSCP), or sending EtherNet/IP messages in 802.1Q tagged frames.
Supported Services
Class: Get_Attribute_Single
Instance: Get_Attribute_Single
Set_Attribute_Single
Class Attributes
Instance Attributes
Extended
# Name Access Type Value
1 Revision Get UINT 0001h (Object revision)
# Name Access Type Value
1 802.1Q Tag
Enable
Set USINT Enables or disables sending 802.1Q frames.
Bit:
Contents:
0 Disabled (Default)
1 Enabled
4 DSCP Urgent Set USINT CIP transport class 1 messages with priority Urgent
Default: 55
5 DSCP
Scheduled
Set USINT CIP transport class 1 messages with priority Scheduled
Default: 47
6 DSCP High Set USINT CIP transport class 1 messages with priority High
Default: 43
7 DSCP Low Set USINT CIP transport class 1 messages with priority Low
Default: 31
8 DSCP Explicit Set USINT CIP UCMM and CIP class 3
Default: 27
