Anybus CompactCom 40 EtherNet/IP User Manual

CIP Objects 70
Doc.Id. HMSI-27-212
Anybus CompactCom 40 EtherNet/IP
Doc.Rev. 1.5
8.6 Connection Manager (06h)
Category
Extended
Object Description
This object is used for connection and connectionless communications, including establishing connec-
tions across multiple subnets.
Supported Services
Class: -
Instance: Get Attribute All
Get Attribute Single
Set Attribute Single
Large_Forward_Open
Forward_Open
Forward_Close
Unconnected Send (when unconnected routing is enabled)
Class Attributes
(No supported class attributes)
Instance Attributes
Extended
# Name Access Type Description
1 Open Requests Set UINT Number of Forward Open service requests received.
2 Open Format Rejects Set UINT Number of Forward Open service requests which were rejected due
to bad format.
3 Open Resource Rejects Set UINT Number of Forward Open service requests which were rejected due
to lack of resources.
4 Open Other Rejects Set UINT Number of Forward Open service requests which were rejected for
reasons other than bad format or lack of resources.
5 Close Requests Set UINT Number of Forward Close service requests received.
6 Close Format Rejects Set UINT Number of Forward Close service requests which were rejected due
to bad format.
7 Close Other Rejects Set UINT Number of Forward Close service requests which were rejected for
reasons other than bad format.
8 Connection Timeouts Set UINT Total number of connection timeouts that have occurred in connec-
tions controlled by this Connection Manager.
