Anybus CompactCom 40 EtherNet/IP User Manual

98
Doc.Id. HMSI-27-212
Anybus CompactCom 40 EtherNet/IP
Doc.Rev. 1.5
9.4 Network Object (03h)
Category
Basic
Object Description
For more information regarding this object, consult the general Anybus CompactCom 40 Software De-
sign Guide.
Supported Commands
Object: Get_Attribute
Instance: Get_Attribute
Set_Attribute
Get_Enum_String
Map_ADI_Write_Area
Map_ADI_Read_Area
Map_ADI_Write_Ext_Area
Map_ADI_Read_Ext_Area
Object Attributes (Instance #0)
(Consult the general Anybus CompactCom 40 Software Design Guide for further information.)
Instance Attributes (Instance #1)
Basic
# Name Access Type Value
1 Network type Get UINT16 009Bh
2 Network type string Get Array of CHAR ‘Ethernet/IP(TM)”
3 Data format Get ENUM 00h (LSB first)
4 Parameter data support Get BOOL True
5 Write process data size Get UINT16 Current write process data size (in bytes)
Updated on every successful Map_ADI_Write_Area
a
a. Consult the general Anybus CompactCom 40 Software Design Guide for further information.
6 Read process data size Get UINT16 Current read process data size (in bytes)
Updated on every successful Map_ADI_Read_Area
a
7 Exception Information Get UINT8 ValueMeaning
0: No information available
1: Invalid assembly instance mapping
2: Missing MAC address
b
b. Exception information only available to Anybus IP
