CIP Objects 62
Doc.Id. HMSI-27-212
Anybus CompactCom 40 EtherNet/IP
Doc.Rev. 1.5
8.2 Translation of Status Codes
If an error occurs when an object is requested from the application, an error code is returned. These
Anybus CompactCom 40 error codes are translated to CIP status codes according to the table below.
For further information about the Anybus CompactCom error codes, please consult the Anybus Com-
pactCom 40 Software Design Guide.
Anybus CompactCom 40 Error Code CIP Status Code
Value Error Value Status
00h Reserved 1Eh Embedded service error
01h Reserved 1Eh Embedded service error
02h Invalid message format 1Eh Embedded service error
03h Unsupported object 05h Path destination unknown
04h Unsupported instance 05h Path destination unknown
05h Unsupported Command 08h Service not supported
06h Invalid CmdExt(0) 14h Depending on Anybus CompactCom Service return-
ing this reply, e.g. attribute not supported
07h Invalid CmdExt(1) - Depending on Anybus CompactCom Service return-
ing this reply
08h Attribute not settable 0Eh Attribute not settable
09h Attribute not gettable 2Ch Attribute not gettable
0Ah Too Much Data 15h Too much data
0Bh Not Enough Data 13h Not enough data
0Ch Out of range 09h Invalid attribute value
0Dh Invalid state 0Ch Object state conflict
0Eh Out of resources 02h Resource unavailable
0Fh Segmentation failure 1Eh Embedded service error
10h Segmentation buffer overflow 23h Buffer overflow
11h Value too high 09h Invalid attribute value
12h Value too low 09h Invalid attribute value
13h Attribute controlled 0Fh A permission/privilege check failed
14h Message channel too small 11h Reply data too large
FFh Object Specific Error 1Fh Vendor specific error. No additional error codes will
be sent on EtherNet/IP
Other - 1Eh Embedded service error
