Anybus CompactCom 40 EtherNet/IP User Manual

97
Doc.Id. HMSI-27-212
Anybus CompactCom 40 EtherNet/IP
Doc.Rev. 1.5
9.3 Diagnostic Object (02h)
General Information
Basic
Object Description
This object provides a standardised way of handling host application events & diagnostics, and is thor-
oughly described in the general Anybus CompactCom 40 Software Design Guide.
Supported Commands
Object: Get_Attribute
Create
Delete
Instance: Get_Attribute
Object Attributes (Instance #0)
Instance Attributes
Basic
In this implementation, the severity level of all instances are combined (using logical ‘OR’) and repre-
sented on the network through the CIP Identity Object.
See also...
• “Diagnostics” on page 18
• “Identity Object (01h)” on page 63 (CIP-object)
# Name Access Data Type Value
1... 4 - - - Consult the general Anybus CompactCom 40 Software
Design Guide for further information.
11 Max no. of instances Get UINT16 5+1 (One instance is reserved for major diagnostic
events.)
12 Supported functionality Get BITS32 00 00 00 00h (Latching events are not supported.)
# Name Access Type Value
1 Severity Get UINT8 Consult the general Anybus CompactCom 40 Software
Design Guide for further information.
2
Event Code
a
a. This attribute can not be represented on the network and is thus ignored by the module.
Get UINT8
3 - - - Not implemented in product.
4
Slot
a
Get UINT16 Consult the general Anybus CompactCom 40 Software
Design Guide for further information.
5
ADI
a
Get UINT16
6
Element
a
Get UINT8
7
Bit
a
Get UINT8
