8.11 Power Management Object (53h)
Category
Extended
Object Description
The Power Management Object provides standardized attributes and services to support the control of
devices into and out of paused or sleep states. The Energy Control Object (F0h) has to be implemented
for this object to gain access to the network.
See also ..
• Energy Control Object (F0h) (Anybus CompactCom 40 Software Design Guide)
Supported Services
Class: Get_Attribute_Single
Instance: Get_Attribute_Single
Power_Management
Set_Pass_Code
Clear_Pass_Code
Class Attributes
Instance Attributes
Extended
# Name Access Type Value
1 Revision Get UINT 0002h (Object revision)
# Name Access Type Value/Description
1 Power Manage-
ment Command
Get DWORD Collection of bit fields comprising the most recent power manage-
ment request.
2 Power Manage-
ment Status
Get DWORD Collection of bit fields providing Power Management status informa-
tion.
3 Client Path Get Struct of: Specifies the EPATH from this instance (server) to its current owner
(client).
UINT (Path Size) Size of path (in words
Padded EPATH
(Path)
4 Number of
Power Manage-
ment Modes
Get UINT Number of Power Management Mode array entries in attribute 5.
