Anybus CompactCom 40 EtherNet/IP User Manual

126
Doc.Id. HMSI-27-212
Anybus CompactCom 40 EtherNet/IP
Doc.Rev. 1.5
9.7 SMTP Client Object (09h)
Category
Extended
Object Description
This object groups functions related to the SMTP-client.
See also...
• “File System” on page 20
• “E-mail Client” on page 32
• “Instance Attributes (Instance #13, SMTP Server)” on page 104
• “Instance Attributes (Instance #14, SMTP User)” on page 105
• “Instance Attributes (Instance #15, SMTP Password)” on page 105
Supported Commands
Object: Get_Attribute
Create
Delete
Send email from file( “Command Details: Send Email From File” on page 129)
Instance: Get_Attribute
Set_Attribute
Send email( “Command Details: Send Email” on page 130)
Object Attributes (Instance #0)
# Name Access Data Type Value
1 Name Get Array of CHAR ‘SMTP Client’
2 Revision Get UINT8 01h
3 Number of instances Get UINT16 -
4 Highest instance no. Get UINT16 -
11 Max. no. of instances Get UINT16 0006h
12 Success count Get UINT16 Reflects the no. of successfully sent messages
13 Error count Get UINT16 Reflects the no. of messages that could not be delivered
