Anybus CompactCom 40 EtherNet/IP User Manual

105
Doc.Id. HMSI-27-212
Anybus CompactCom 40 EtherNet/IP
Doc.Rev. 1.5
Instance Attributes (Instance #14, SMTP User)
This instance holds user name for the SMTP account.
Extended
Instance Attributes (Instance #15, SMTP Password)
This instance holds the password for the SMTP account. Changes are valid after reset.
Extended
# Name Access Type Description
1
Name
a
a. Multilingual, see “Multilingual Strings” on page 107.
Get Array of CHAR ‘SMTP User’
2 Data type Get UINT8 07h (= CHAR)
3 Number of elements Get UINT8 40h
4 Descriptor Get UINT8 07h (read/write/shared access)
5 Value Get/Set Array of CHAR Any change is valid after reset.
SMTP account user name, 64 characters
6 Configured Value Get Array of CHAR Holds the configured value, which will be written to attribute
#5 after the module has been reset.
SMTP account user name , 64 characters
# Name Access Type Description
1
Name
a
a. Multilingual, see “Multilingual Strings” on page 107.
Get Array of CHAR ‘SMTP Pswd’
2 Data type Get UINT8 07h (= CHAR)
3 Number of elements Get UINT8 40h
4 Descriptor Get UINT8 07h (read/write/shared access)
5 Value Get/Set Array of CHAR Any change is valid after reset.
SMTP account password, 64 characters
6 Configured Value Get Array of CHAR Holds the configured value, which will be written to attribute
#5 after the module has been reset.
SMTP account password, 64 characters
