Instance Attributes (Instance #16, MDI 1 settings)
This instance holds the settings for MDI/MDIX 1. Changes have immediate effect.
Extended
Instance Attributes (Instance #17, MDI 2 settings)
This instance holds the settings for MDI/MDIX 2. Changes have immediate effect.
Extended
Instance Attributes (Instances #18 and #19)
These instances are reserved for future attributes.
# Name Access Type Description
1 Name Get Array of CHAR ‘MDI 1’
2 Data type Get UINT8 08h (= ENUM)
3 Number of elements Get UINT8 01h
4 Descriptor Get UINT8 07h (read/write/shared access)
5 Value Get/Set ENUM Value:Enum. String:Meaning:
00h ‘Auto’ (default)
01h ‘MDI’
02h ‘MDIX’
6 Configured Value Get ENUM Holds the configured value, which will be written to attribute
#5.
Value:Enum. String:Meaning:
00h ‘Auto’ (default)
01h ‘MDI’
02h ‘MDIX’
# Name Access Type Description
1 Name Get Array of CHAR ‘MDI 2’
2 Data type Get UINT8 08h (= ENUM)
3 Number of elements Get UINT8 01h
4 Descriptor Get UINT8 07h (read/write/shared access)
5 Value Get/Set ENUM Value:Enum. String:Meaning:
00h ‘Auto’ (default)
01h ‘MDI’
02h ‘MDIX’
6 Configured Value Get ENUM Holds the configured value, which will be written to attribute
#5.
Value:Enum. String:Meaning:
00h ‘Auto’ (default)
01h ‘MDI’
02h ‘MDIX’
