Technical Specification 194
Doc.Id. HMSI-27-212
Anybus CompactCom 40 EtherNet/IP
Doc.Rev. 1.5
E.2 Protective Earth (PE) Requirements
In order to ensure proper EMC behaviour, the module must be properly connected to protective earth
via the PE pad / PE mechanism described in the general Anybus CompactCom 40 Hardware Design
Guide.
HMS Industrial Networks does not guarantee proper EMC behaviour unless these PE requirements are
fulfilled.
E.3 Power Supply
Supply Voltage
The module requires a regulated 3.3V power source as specified in the general Anybus CompactCom 40
Hardware Design Guide.
Power Consumption
The Anybus CompactCom 40 EtherNet/IP is designed to fulfil the requirements of a Class B module.
For more information about the power consumption classification used on the Anybus CompactCom
40 platform, consult the general Anybus CompactCom 40 Hardware Design Guide.
The current hardware design consumes up to 360 mA
1
.
Note: It is strongly advised to design the power supply in the host application based on the power con-
sumption classifications described in the general Anybus CompactCom Hardware Design Guide, and
not on the exact power requirements of a single product.
E.4 Environmental Specification
Consult the Anybus CompactCom 40 Hardware Design Guide for further information.
E.5 EMC Compliance
Consult the Anybus CompactCom 40 Hardware Design Guide for further information.
1. Note that in line with HMS policy of continuous product development, we reserve the right to change the
exact power requirements of this product without prior notification. Note however that in any case, the
Anybus CompactCom 40 EtherNet/IP will remain as a Class B module.
