Anybus CompactCom 40 EtherNet/IP - 8.13 Port Object (F4 h)

CIP Objects 85
Doc.Id. HMSI-27-212
Anybus CompactCom 40 EtherNet/IP
Doc.Rev. 1.5
8.13 Port Object (F4h)
Category
Extended
Object Description
The Port Object describes the CIP ports present on the device. Each routable CIP port is described in
a separate instance. Non-routable ports may be described. Devices with a single CIP port are not re-
quired to support this object.
The object exists only if enabled in the EtherNet/IP Host Object (Instance Attribute #17).
See also...
• “EtherNet/IP Host Object (F8h)” on page 161 (Anybus Module Object)
• “CIP Port Configuration Object (0Dh)” on page 153 (Host Application Object)
Supported Services
Class: Get_Attributes_All
Get_Attribute_Single
Instance: Get_Attributes_All
Get_Attribute_Single
Class Attributes
# Name Access Type Value
1 Revision Get UINT Object revision (Current value = 0001h)
2 Max Instance Get UINT Max. instance number
3 Number of Instances Get UINT Number of ports currently created.
8 Entry Port Get UINT Returns the instance of the Port Object that describes the port
through which this request entered the device.
9 Port Instance Info Get Array of: Array of structures containing instance attributes 1 and 2 from
each instance. The array is indexed by instance number, up to
the maximum number of instances. The value at index 1 (off-
set 0) and any non-instantiated instances will be zero.
Struct of:
UINT (Type)
UINT (Number)
Enumerates the type of port (see instance attribute #1)
CIP port number associated with this port (see instance attrib-
ute #2)
