CIP Objects 84
Doc.Id. HMSI-27-212
Anybus CompactCom 40 EtherNet/IP
Doc.Rev. 1.5
Instances Attributes
Each instance corresponds to an instance within the Application Data Object (for more information,
consult the general Anybus CompactCom 40 Software Design Guide).
Extended
# Name Access Type Description
1 Name Get SHORT_STRING Parameter name (Including length)
2 ABCC Data type Get Array of USINT Data type of instance value
3 No. of Elements Get USINT Number of elements of the specified data type
4 Descriptor Get Array of USINT Bit field describing the access rights for this instance
Bit:
Meaning:
0 Set = Get Access
1 Set = Set Access
5
Value
a
a. Converted to/from CIP standard by the module
Get/Set Determined by
attribute #2
Instance value
6
Max Value
a
Get The maximum permitted parameter value.
7
Min Value
a
Get The minimum permitted parameter value.
8
Default Value
a
Get The default parameter value.
9 Number of subelements Get UINT Number of subelements in the ADI. Default value is 1
unless implemented in the application.
