CIP Objects 90
Doc.Id. HMSI-27-212
Anybus CompactCom 40 EtherNet/IP
Doc.Rev. 1.5
8.15 Ethernet Link Object (F6h)
Category
Extended
Object Description
This object maintains link specific counters and status information for an IEEE 802.3 communications
interface. Exactly one instance for each communications interface on the module is supported. Instances
for internally accessible interfaces can also be supported.
See also...
• “Communication Settings” on page 16
• “Network Configuration Object (04h)” on page 99 (Anybus Module Object)
Supported Services
Class services: Get_Attribute_All
Get_Attribute_Single
Instance services: Get_Attribute_All
Get_Attribute_Single
Set_Attribute_Single
Get_And_Clear
Class Attributes
By default, three instances (port 1, port 2 and the internal port) are implemented, meaning that two ports
are activated.
If port 2 is inactivated in the Port 2 State attribute of the Ethernet Host Object (F9h), only one instance
(port 1) should be implemented.
# Name Access Type Value
1 Revision Get UINT 0004h (Object revision)
2 Max instance Get UINT 1 or 3 (Maximum instance number)
3 Number of
instances
Get UINT 1 or 3 (Number of instances)
6 Maximum ID
Number Class
Attributes
Get UINT 7 (The attribute number of the last implemented class attribute.)
7 Maximum ID
Number
Instance Attrib-
utes
Get UINT 11 (The attribute number of the last implemented instance attribute.)
