CIP Objects 89
Doc.Id. HMSI-27-212
Anybus CompactCom 40 EtherNet/IP
Doc.Rev. 1.5
9 Mcast Config Get/Set Struct of: IP multicast configuration.
Alloc Control USINT 0 Value:
0:
1:
Meaning:
Use default allocation algorithm to gener-
ate multicast addresses
Allocate multicast addresses according to
the values in the ‘Num Mcast’- and ‘Mcast
Start Addr’-fields.
(reserved) USINT 0 Set to zero. Do not change.
Num Mcast UINT 1 Number of multicast addresses to allocate for Eth-
erNet/IP
Mcast Start
Addr
UDINT - Starting multicast address from which to begin allo-
cation
10
b
SelectAcd Set Bool 1 Value:
0:
1:
Meaning:
Disable ACD
Enable ACD (Default)
If ACD (address conflict detection) is
enabled, bit 6 in attribute #1 will be set if an
ACD conflict is detected. The Network Sta-
tus LED will also indicate a detected con-
flict, see “Network Status LED” on page
193.
11
b
LastConflictDe-
tected
Set Struct of: ACD Diagnostic parameters Related to the last
conflict detected.
AcdActiviity USINT - State of ACD activity when last conflict
detected.
RemoteMAC ARRAY of 6 USINT - MAC address of remote node form the
ARP PDU in which a conflict was detected.
ArpPdu ARRAY of 28 USINT - Copy of the raw ARP PDU in which a con-
flict was detected.
12 EIP QuickCon-
nect
c
,
d
Set Bool 0 Value:
0:
1:
Meaning:
Disable EIP QuickConnect (Default)
Enable EIP QuickConnect
If EIP QuickConnect is enabled, the Quick-
Connect feature will direct EtherNet/IP tar-
get devices to quickly power up and join an
EtherNet/IP network.
13 Encapsulation
inactivity time-
out
Set UINT 0 - 3600 Number of seconds of inactivity before a TCP con-
nection is closed.
0: Disabled
a. Support for configuring network settings from the network can be disabled by implementing attribute #9 in the Eth-
erNet/IP Host Object, see “Instance Attributes (Instance #1)” on page 162.
b. Attributes #10 and #11 will not be available if ACD is disabled using attribute #11 in the Ethernet Host Object
(F9h).
c. If the module is configured to use EIP QuickConnect functionality, the EDS file has to be changed. As the EDS file
is changed, the identity of the module has to be changed and the module will require certification, see “Conform-
ance Test Guide” on page 12.
d. This attribute exists if attribute #26 in the EtherNet/IP Host Object is implemented, see “Instance Attributes
(Instance #1)” on page 162.
# Name Access Type Value Comments
