158

Doc.Id. HMSI-27-212

Anybus CompactCom 40 EtherNet/IP

Doc.Rev. 1.5

10.3 CIP Identity Host Object (EDh)

Category

Extended

Object Description

This object allows for applications to support additional CIP identity instances. It is used to provide ad-

ditional product identity information, e.g. concerning the software installed.

The first instance in the CIP identity object will not change its behavior. When implementing instances

in the CIP identity host object, they will be mapped to the CIP identity object starting at instance 2. In-

stance no. 1 in the CIP identity host object will be mapped to instance no. 2 in the CIP identity object

and so on.

See also...

• “Identity Object (01h)” on page 63 (CIP)

Supported Commands

Object: Get_Attribute

Instance: Get_Attribute

Get_Attribute_All

Object Attributes (Instance #0)

Instance Attributes (Instance #1)

Extended

# Name Access Data Type Value Description

1 Name Get STRING ‘CIP Identity’ Object name

2 Revision Get UINT8 01h Object revision

3 Number of instances Get UINT16 Depends on application Supported number of instances

4 Highest instance no. Get UINT16 Depends on application Highest implemented instance

# Name Access Type Default Value Comment

1 Vendor ID Get UINT16 - These values replace the values for the CIP

identity object instance #2 and upwards.

See also...

- “Identity Object (01h)” on page 63 (CIP-

object)

2 Device Type Get UINT16 -

3 Product Code Get UINT16 -

4 Revision Get struct of:

UINT8 Major

UINT8 Minor

-

5 Status Get UNIT16 -

6 Serial Number Get UINT32 -

7 Product Name Get Array of CHAR -

Anybus CompactCom 40 EtherNet/IP User Manual
