Anybus CompactCom 40 EtherNet/IP User Manual

160
Doc.Id. HMSI-27-212
Anybus CompactCom 40 EtherNet/IP
Doc.Rev. 1.5
10.1 Sync Object (EEh)
Category
Extended
Object Description
The Anybus CompactCom 40 EIP does not support CIP Sync. This object is only used to store the cycle
time for the last established IO connection that consumes data.
Supported Commands
Object: Get_Attribute
Instance: Get_Attribute
Set_Attribute
Object Attributes (Instance #0)
(Consult the general Anybus CompactCom 40 Software Design Guide for further information.)
Instance Attributes (Instance #1)
Extended
The attributes are represented on EtherNet/IP as follows:
# Name Access Type Default Value Comment
1 Cycle time Get/Set UINT32 The RPI for the last established IO connec-
tion that consumes data (O->T RPI)
2-8 (not implemented)
