Anybus CompactCom 40 EtherNet/IP User Manual

171
Doc.Id. HMSI-27-212
Anybus CompactCom 40 EtherNet/IP
Doc.Rev. 1.5
10.3 Ethernet Host Object (F9h)
Category
Basic, extended
Object Description
This object implements Ethernet features in the host application.
Supported Commands
Object: Get_Attribute
Instance: Get_Attribute
Set_Attribute
Object Attributes (Instance #0)
Instance Attributes (Instance #1)
Basic
# Name Access Data Type Value
1 Name Get Array of CHAR ‘Ethernet’
2 Revision Get UINT8 02h
3 Number of instances Get UINT16 0001h
4 Highest instance no. Get UINT16 0001h
# Name Access Type
Default
a
a. If an attribute is not implemented, the module will use this value instead
Comment
1
MAC address
b
b. The module is pre-programmed with a valid Mac address. To use that address, do not implement this attribute.
Get Array of UINT8 - 6 byte physical address value; overrides the
pre-programmed Mac address. Note that the
new Mac address value must be obtained from
the IEEE.
