Anybus CompactCom 40 EtherNet/IP User Manual

170
Doc.Id. HMSI-27-212
Anybus CompactCom 40 EtherNet/IP
Doc.Rev. 1.5
Command Details: Get_Configuration_Data
Details
Command Code: 13h
Valid for: Object Instance
Description
If the configuration data is requested from the network, the Anybus will issue this command to the ap-
plication. The application shall send the stored configuration data in the response message.
Segmentation is used since the telegram length on the host interface is limited. The maximum total
amount of configuration data that will be accepted by the module is 458 bytes.
Note: This command must be implemented in order to support Configuration Data. If not implement-
ed, the request will be rejected by the Anybus module.
• Command Details
• Response Details (Success)
• Response Details (Error)
See also...
“Message Segmentation” on page 189
Field Contents Notes
CmdExt[0] 00h -
CmdExt[1] 00h -
MsgData[0... n] - No extended message data
Field Contents Notes
CmdExt[0] 00h (reserved, set to zero)
CmdExt[1] Segmentation Control bits See “Message Segmentation” on page 189
MsgData[0 - n] Status Configuration data from the application
Field Contents Notes
CmdExt[0] 00h (reserved, set to zero)
CmdExt[1] Segmentation Control bits See “Message Segmentation” on page 189
MsgData[0] Status Anybus protocol error code
